Mini HDMI Splitter 4 port

The Mini 4 Port HDMI Splitter allows you to distribute a single HDMI source to up to four displays simultaneously while maintaining high-quality video and audio performance. Supporting resolutions up to 4K Ultra HD at 60Hz, this splitter is ideal for home entertainment, retail displays, conference rooms, hospitality venues, and digital signage. Its durable metal housing, gold-plated HDMI connectors, and HDCP 2.2 compatibility ensure reliable signal transmission across multiple displays.

Key Features

• 4 HDMI Outputs: Connect one HDMI source to four displays simultaneously.
• 4K Ultra HD Support: Supports resolutions up to 3840 × 2160 at 60Hz.
• HDCP 2.2 Compatible: Supports protected digital content for modern devices.
• High-Speed Performance: Maximum bandwidth of 600MHz with data rates up to 6Gbps.
• Premium Audio Support: Compatible with DTS-HD, Dolby TrueHD, DTS, Dolby AC3, and DSD audio formats.
• Gold-Plated HDMI Connectors: Provides reliable signal transmission and corrosion resistance.
• Durable Metal Chassis: Designed for long-lasting performance in home and commercial installations.
• Easy Installation: Simple plug-and-play setup with included UK power adaptor.

What's Included

• 1 × Mini 4 Port HDMI Splitter
• 1 × UK Power Adaptor
• User Guide

Specifications

• Product Type: HDMI Splitter
• HDMI Input: 1
• HDMI Outputs: 4
• Maximum Resolution: 3840 × 2160 (4K UHD) at 60Hz
• HDCP Version: 2.2
• Maximum Bandwidth: 600MHz
• Maximum Data Rate: 6Gbps
• Colour Depth: 8-bit, 10-bit and 12-bit Deep Colour
• Supported Audio Formats: DTS-HD, Dolby TrueHD, DTS, Dolby AC3, DSD
• Transmission Distance:
  • Up to 35m at 4K 30Hz or Full HD
  • Up to 10m at 4K 60Hz
• Power Supply: AC 100–240V Input, DC 5V/1A Output
• Maximum Working Current: 650mA
• Operating Temperature: -15°C to +55°C
• Dimensions: 178 × 67 × 23mm
• Weight: 230g

Compatible Devices

• 4K Televisions
• Computer Monitors
• Projectors
• Gaming Consoles
• Blu-ray Players
• Streaming Devices
• Desktop PCs
• Laptops with HDMI output

Applications

• Home cinema systems
• Retail and digital signage
• Conference rooms
• Hotels and hospitality
• Gaming setups
• Commercial AV installations

Benefits

• Display one HDMI source on four screens simultaneously
• Supports modern 4K 60Hz video formats
• Maintains excellent picture and audio quality
• Robust metal construction for reliable operation
• Quick and simple installation
• Ideal for both residential and commercial environments

Why Choose This Mini 4 Port HDMI Splitter?

The Mini 4 Port HDMI Splitter provides a dependable solution for distributing a single HDMI signal across multiple displays. With support for 4K Ultra HD at 60Hz, HDCP 2.2 compatibility, premium audio formats, and a durable metal enclosure, it is an excellent choice for entertainment systems, business presentations, retail environments, and professional AV installations.
