Mercusys MB115-4G Wireless Router Fast Ethernet Single-Band (2.4 GHz) Black

The Mercusys MB115-4G is a versatile 4G LTE wireless router that provides fast internet access wherever a compatible mobile network is available. Simply insert a Nano SIM card and connect your devices without complicated configuration. Supporting 4G download speeds of up to 150Mbps and 2.4GHz WiFi speeds of up to 300Mbps, it can share a mobile internet connection with up to 32 WiFi devices.

Four external antennas help provide stable wireless coverage, while the integrated LAN/WAN port allows the router to operate as a conventional WiFi router when a wired internet connection is available.

Key Features

• 4G LTE Connectivity: Access broadband internet through a compatible mobile SIM card.
• Up to 150Mbps 4G Download Speed: Enjoy fast mobile broadband for browsing, streaming, work, and everyday connectivity.
• 300Mbps WiFi: Provides wireless speeds of up to 300Mbps over the 2.4GHz band.
• Up to 32 WiFi Devices: Share your mobile internet connection with multiple smartphones, laptops, tablets, smart TVs, and other devices.
• Nano SIM Slot: Insert a compatible Nano SIM card for quick mobile broadband access.
• Four External Antennas: Designed to provide stable and efficient wireless coverage.
• Router Mode: Use the LAN/WAN port with an Ethernet connection when 4G service is unavailable.
• Plug and Play Setup: SIM-based operation helps minimise complicated configuration.

Wireless Connectivity

• Wireless Standard: IEEE 802.11b/g/n
• Wireless Frequency: 2.4GHz
• Maximum WiFi Speed: 300Mbps
• Wireless Security: WPA-PSK / WPA2-PSK
• WMM Support: Yes
• Wireless Schedule: Supported
• Wireless Statistics: Supported
• Wireless Radio: Enable/Disable

4G LTE Network Support

• 4G LTE Download Speed: Up to 150Mbps
• EU FDD-LTE: B1 / B3 / B5 / B7 / B8 / B20 / B28
• EU TDD-LTE: B38 / B40
• HSPA+ / UMTS: B1 / B5 / B8
• SIM Type: Nano SIM

Wired Connectivity

• 1 × 10/100Mbps LAN/WAN Port
• 3 × 10/100Mbps LAN Ports
• Ethernet Router Mode Supported

Hardware Specifications

• Product Model: MB115-4G
• Product Type: 4G LTE Wireless Router
• WiFi Standard: Wireless N
• Frequency Band: 2.4GHz
• Maximum Wireless Speed: 300Mbps
• SIM Slot: 1 × Nano SIM
• WPS Button: Yes
• Reset Button: Yes
• DHCP Server: Yes
• Colour: Black
• Dimensions: 219 × 140 × 32mm

Network Security

• WPA-PSK Encryption
• WPA2-PSK Encryption
• WPS Support

What's Included

• 1 × Mercusys MB115-4G 4G LTE Wireless Router
• 1 × Power Adapter
• 1 × RJ45 Ethernet Cable
• 1 × Quick Installation Guide

Applications

• Home internet access
• Temporary internet connections
• Rural and remote locations
• Holiday homes and caravans
• Small offices
• Backup internet connectivity
• Mobile broadband access
• Smart home connectivity

Benefits

• Fast 4G LTE internet without a fixed broadband connection
• Easy SIM-based setup
• Connects up to 32 wireless devices
• 300Mbps 2.4GHz WiFi performance
• Four external antennas for stable wireless coverage
• Four Ethernet ports for wired devices
• LAN/WAN functionality for flexible internet access
• Compact design suitable for home and office environments

Installation Note

Insert an unlocked compatible Nano SIM card into the router and connect the supplied power adapter. The router can then provide 4G LTE internet access over WiFi and Ethernet. For router mode using a wired broadband connection, connect an Ethernet cable to the LAN/WAN port.

Important: Ensure the SIM card is unlocked and compatible with the supported network bands before use. Actual network speeds and coverage depend on the mobile network operator, signal strength, network conditions, and service plan.

Operating Environment

• Operating Temperature: 0°C to 40°C
• Storage Temperature: -40°C to 60°C
• Operating Humidity: 10% to 90%, non-condensing
• Storage Humidity: 5% to 90%, non-condensing

Why Choose the Mercusys MB115-4G?

The Mercusys MB115-4G offers a convenient way to create a reliable internet connection using a compatible 4G SIM card. With 150Mbps-class LTE download performance, 300Mbps 2.4GHz WiFi, support for up to 32 wireless devices, multiple Ethernet ports, and four external antennas, it is a flexible networking solution for homes, offices, remote locations, and backup internet access.
