Eagle (Dahua) 5MP Smart Dual Light HDCVI Fixed-focal Camera Grey

Capture crisp, full-colour video day and night with the Eagle 5MP Smart Dual Light HDCVI Turret Camera (Grey). Powered by Dahua’s intelligent dual-light technology, this fixed-focal turret camera delivers 5 MP resolution and uses a combination of infrared and white-light LEDs to ensure detailed colour images even in low-light conditions. It supports multi-format video outputs (HDCVI / CVBS / AHD / TVI), audio-over-coax transmission, and a rugged IP67-rated housing for reliability outdoors. The smart light algorithm illuminates only when needed, reducing light pollution while preserving image clarity.

Ideal for home, business, or perimeter surveillance systems, this camera blends seamless integration with high performance to give you reliable, always-on monitoring.

Key Features

• Smart Dual Light: combines IR + white-light LEDs so colour images are captured when motion is detected; IR only when no motion
• 5 MP resolution (2880 × 1620) at up to 25 fps
• Fixed 2.8 mm lens with wide field-of-view
• Four-signal transmission over one coaxial cable: video, audio*, data, power
• Switchable output formats: HDCVI / CVBS / AHD / TVI
• Built-in microphone for audio capture
• Super Adapt algorithm for adjusting image settings in varying lighting
• Rugged IP67-rated enclosure for dust and water protection
• Wide voltage tolerance (12 V DC ±30 %)
• Long-range transmission: up to ~700 m (for 5 MP over coax)
• Multi-language OSD menus and standard camera controls (WB, shutter, gain, mask)

Specifications

• Image & Optics
• Image sensor: 5 MP CMOS
• Maximum resolution: 2880 (H) × 1620 (V)
• Lens: fixed-focal 2.8 mm
• Aperture: F1.6
• Field of View (2.8 mm): approx. H: 106°, V: 56°, Diagonal ~125°
• Close focus distance: ~0.8 m
• Electronic shutter: 1/25 s to 1/100,000 s (PAL), 1/30 to 1/100,000 s (NTSC)
• SNR: > 65 dB

Illumination & Light

• IR + white light dual LEDs
• Illumination distance: up to 20 m for both IR and warm light
• Light control: auto / manual / smart mode
• Number of illuminators: 1 IR + 1 warm light

Video & Format

• Output formats: HDCVI, CVBS, AHD, TVI
• Frame rate: up to 25 fps @ 5 MP (16:9)
• Day/Night mode: Auto (ICR) / Colour / B&W
• WDR / DWDR, BLC / HLC support
• Noise reduction: 2D NR
• Mirror / flip / privacy mask features

Audio & Transmission

• Audio: built-in microphone (audio over coax)
• Transmission: supports 4 signals over one coax (video, audio*, data, power)
• Long distance support: up to 700 m for 5 MP over coaxial cable
• Power & Environment
• Power supply: 12 V DC ±30 %
• Power consumption: maximum ~3.1 W (when white light is on)
• Operating temperature: –40 °C to +60 °C
• Humidity: ≤ 95% non-condensing
• Ingress protection: IP67

Mechanical & Physical

• Housing: metal / durable construction
• Dimensions: ~φ94.0 mm × 85.7 mm (housing)
• Net weight: ~0.31 kg
• Mounting: wall, ceiling, pole mount compatible

Package Includes

• 1 × Eagle (Dahua) 5MP Smart Dual Light HDCVI Turret Camera (Grey)
• Mounting screws & anchors
• Mounting template / guide
• Instruction / Quick Start Guide
• Waterproof connector (if applicable)
• Warranty documentation
