CWT 1000W Gold 80+ Fully Modular ATX3.0 PCIe 5.0 Power Supply
-
Modular Cable Configuration - A Modular cable management design lets you use only the cables you need. You get to save space and create a cleaner-looking build and improve airflow.
-
80 Plus Gold Certification - 80 Plus Gold certified with 90percent efficiency, high efficiency operation lowering energy consumption, noise, temperatures and less energy gets wasted during power conversion, the lower the operating costs will be for the user.
-
PCIe 5.0 Ready - The CSZ1000V5 includes a 12VHPWR 16-Pinconnector offering a powerful and stable performance allowing the PSU to run next-generation GPUs, RTX 3090 TI/PCIe 5.0 GPUs. Max. Power output up to 600W.
-
Japanese 105 Degree Celsius-Rated Capacitors - Using Japanese industrial-grade capacitors, CSZ1000V5 power supplies offer the fixed power and long-term reliability.
-
Low Noise Operation - A 140mm Black fluid dynamic bearing fan with a zero RPM fan mode allows for the PSU fan to be completely off when it is not needed. It will automatically turn the fan on when your PC reaches a certain temperature. It keeps the fan noise down, even when operating at full load.
-
Hardware Protection - A full line up top tier circuit protections keeps your build running strong and your hardware safe - OVP (Over Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), SCP (Short Circuit Protection), UVP (Under Voltage Protection) & OTP (Over Temperature Protection).
Specifications
PSU Specifications
AC INPUT: 100-240 VAC 13A 50-60Hz
DC Output
+3.3V +5V +12V1 -12V +5VSB
22A 22A 83.5A 0.3A 3A
Max
1000W
Connectors
20+4 Pin Main Connectors: 1 (Modular)
4+4 Pin 12V Connectors: 2 (Modular)
SATA Connectors: 12 (Modular)
4-Pin Molex Connectors: 4 (Modular)
6+2 Pin PCI-e Connectors: 4 (Modular)
Floppy Drive Connectors: 1 (Modular)
Detailed Specifications
Dimensions:150mm x 87mm x 150mm (W x H x D)
Input Voltage:100-240 VAC
Input Current:13A
Input Frequency Range:50-60Hz
PFC:Active PFC
Power Good Signal:100-150ms
Hold Up Time:>16ms at 80 Percent Load
Efficiency:90%
MTBF:100,000 Hours
Protection:OPP / SCP / UVP / OVP / OCP / OTP
Power:1000W
Operation Temperature:0-40°C
Safety:CB / CE / UKCA / TUV / CTUV us / ErP / RoHS / WEEE
Cooling:140mm FDB Fan
Noise:44.5dBA
80 Plus Certified:Yes - 80 Plus Gold
| Part Number | CSZ1000V5 |
|---|---|
| EAN / UPC | 5055492413291 |
