Ace 750w Power supply Black Flat Cables (includea 1 x pci-e connector, 1 x 8 pin cpu connector)

The Ace 750W ATX Power Supply provides dependable power for desktop PCs, home systems, and entry-level gaming builds. Designed with passive Power Factor Control (PFC), a quiet 120mm cooling fan, and flat black cables, it delivers stable power while helping maintain good airflow inside your computer case. Compatible with a wide range of ATX motherboards and modern PC components, it offers an affordable solution for new builds and system upgrades.

Key Features

• 750W Power Output: Suitable for a wide range of desktop PC configurations.
• Passive Power Factor Control: Improves power stability and efficiency.
• 120mm Cooling Fan: Provides quiet and effective cooling.
• Flat Black Cables: Simplifies cable management and improves airflow.
• ATX Compatible: Supports ATX 12V compliant motherboards and processors.
• Essential Protection: Includes over-voltage, under-voltage and over-power protection.
• Quiet Operation: Low-noise fan rated below 17dBA.

What's Included

• 1 × Ace 750W ATX Power Supply
• User Manual
• Cable Ties
• Mounting Screws

Specifications

• Brand: Ace
• Model: A-750BR-BLK
• Product Type: ATX Power Supply
• Rated Power: 750W
• ATX Version: ATX 1.3 / 2.03
• Input Voltage: 230V AC
• Input Current: 5A
• Input Frequency: 50–60Hz
• Power Factor Control: Passive PFC
• Efficiency: Up to 75%
• Cooling Fan: 120mm Black Fan
• Noise Level: Less than 17dBA
• Power Good Signal: 150–450ms
• Hold-Up Time: 1–40ms
• Operating Temperature: Up to 45°C
• MTBF: 100,000 Hours
• Dimensions: 150 × 140 × 85mm
• Colour: Black

Power Connectors

• 1 × 6+2 Pin PCIe Connector
• 6 × SATA Power Connectors
• 1 × Molex Connector

Protection Features

• Over Voltage Protection (OVP)
• Under Voltage Protection (UVP)
• Over Power Protection (OPP)

Certifications

• CE
• UKCA
• RoHS
• WEEE

Applications

• Desktop PC builds
• Home computers
• Office systems
• Entry-level gaming PCs
• PC upgrades
• General computing

Benefits

• Reliable power delivery for everyday systems
• Quiet cooling with a large 120mm fan
• Improved cable management with flat cables
• Compatible with most ATX motherboards
• Built-in electrical protection for system safety
• Easy installation for new and upgraded PCs

Why Choose the Ace 750W ATX PSU?

The Ace 750W ATX Power Supply offers dependable performance, quiet operation, and essential protection features at an affordable price. Its ATX compatibility, flat black cables, and efficient cooling make it an excellent choice for home computers, office systems, and entry-level gaming builds.
